Waterproof LED
linear bar series
50W DLC approved fixture
- Extruded aluminium housing
with polycarbonate cover and ends
- Mounting flexibility:
can be ceiling mounted, wall mounted and pendant
- Adjustable mounting kit included
- Lower constant current to drive the
LED
to insure the lifespan and light decay
- IP65 ingress protection
- Superior LED chip
to ensure high efficiency and energy saving
- Eco-friendly; no UV, no lead, no
mercury
- Input voltage 110V-277V 50Hz-60Hz.
- Operating ambient
temperature: -20 ͦC to +45 ͦC
Features:
- Unique patent design, DLC, ERP,
CE certified
- Water-proof, Dust-proof, Damp-proof, Pressure-proof
- High luminous efficiency 100 -110LM/W
- Excellent heat dissipation support stable quality
- Convention installation for linking in series
- Long lifespan
- Energy saving up to 80%
- Solid and durable housing
Applications:
- Residential, commercial and industrial
- Indoor / Outdoor
- Parking place / Tunnel / Corridor / Gallery
Railway / Bus / MTR Station / Warehouse / Factory
Airport / Exhibition Hall / Supermarket / Gas station
Specifications:
- Material: Aluminium, PC, ABS
- Wattage: 50W
- Lumen: 5500lm
- LED quantity: 288
- CRI: >80
- Input: AC100-277V
- Dimensions: 1200* 91* 74 (mm)
- Body Color: Grey
- Light Color: Cool White 6000K
- cETL certified
|
